USB option for Korg Monotribe UM-Q110
The best, cheapest and most convinient 1-in/1-out AU123 chip based USB MIDI module for Korg Monotribe, DIY and other applications that require MIDI connection via USB. Complies with USB 2.0 specification. No need to install extra drivers for Windows 98 SE, Windows XP, Windows ME, Windows 2000, Windows Vista, Windows 7. Connector pinout is compatible with Korg Monotribe MIDI option connector. All wires and accessories are included. Product may look different.
Specification:
• USB 2.0 full speed operation
• Compliant with USB Audio Device Class Specification v1.0
• Output format: MIDI TTL/CMOS, 3.3V/5V compatible
• Input format: MIDI TTL/CMOS, 5V tolerant
• Easy to connect and install
• Power supply: 5V, USB
• Consumption current: 10mA approx.
• Components used: Altmustech, TDK, AMP
• Dimensions (mm): 27x12x23
The best, cheapest and most convinient 1-in/1-out AU123 chip based USB MIDI module for Korg Monotribe, DIY and other applications that require MIDI connection via USB.
Korg Monotribe USB option module
Korg Monotribe USB option module
The best, cheapest and most convinient 1-in/1-out AU123 chip based USB MIDI module for Korg Monotribe, DIY and other applications that require MIDI connection via USB.
Feautures:
• MIDI Channel 1 (from synth sequencer) and Channel 10 (rhythm sequencer) send MIDI Note ON/OFF
messages to external devices from the Monotribe sequencer
• Front panel knobs and switches variously send Continuous Controllers 1, 7, 11, 16, 17, 80, 81, 82 and 83
• Record knob tweaks and switch actions over MIDI
• Monotribe MIDI sync functions as a MIDI Clock/Sync Pulse converter using the Monotribe's Sync connectors
• Transport control over MIDI
• Start, Stop, Continue external sequencer with front panel buttons
• Modify the synthesizer VCA and LFO modules with standard MIDI Continuous Controller messages
1, 7, 11, 16, 17, 80, 81, 82 and 83 on MIDI channel 1
• Play synthesizer with MIDI Note ON/OFF messages on channel 1
• Play drum sounds with MIDI Note ON/OFF messages on channel 10
• Transport control over MIDI. Start, Stop, Continue and Sync Monotribe from external sequencer
